3D Buildability Analysis

Errors in 3D models cost the owners a lot

The first question we usually get from new customers is whether the service we offer is not undertaken by the architect or engineer. And yes, that’s right. The architect or engineer has probably promised the building owner that he knows what he is doing and has possibly even made (his own) ICT contract. And then the owner has to rely on it.

But the construction industry is under pressure. Danish building owners are increasingly having problems with the 3D models they receive from architects or engineers – often they can not be used directly in the execution. This is usually because the projects are not coordinated across disciplines, resulting in collisions in the form of geometric errors in the project material. In addition, various file formats and programs create confusion.

“We had a number of challenges with exceeding the budget in connection with the first phase of the Jutland Hospital in Aabenraa. Much of the budgetary challenges were due to inadequate or incorrect project material. To avoid the same challenges in Phase 2, we asked Exigo to perform a risk analysis of the engineer’s 3D project material. “

“(…) I am confident that their risk analysis will have a positive impact on a more robust budget before being tendered in Phase 2. I highly recommend the risk analysis conducted by Exigo.”

Get an overview with the 3D buildability analysis

Exigo has over the last 10 years helped clients to detect collisions in prepared building materials. We analyze the quality of the 3D models and give you an overview of the following errors in the models:

  • General conditions: File formats, naming, structure and position (x, y, z)
  • Consistency: Levels of development, classification, modeling techniques
  • Geometric quality: Severe collisions, significant collisions, less severe collisions

Let us take a look at the models for you

We have the necessary IT technology training and therefore know the DNA of the 3D models to the smallest detail. Regardless of which review we perform, we always start with a thorough analysis of the structure and quality of the 3D models. If we have your consent, we get access to the 3D models, for example via the project web. We conduct the audit either as an “in-depth analysis” or as a “trial”.

Read the Danish Construction Agency’s overview of typical design flaws. You can also learn how to use 3D building models at our 3-day course at Exigo.

At Exigo we have many satisfied customers who benefit greatly from our consultancy. Read what they say about us.

Avoid unforeseen costs

Experience shows that our customers can save at least 20% on unforeseen costs with continuous collision control. Our 3D buildability analysis reduces the number of collisions by approximately 90% compared to the traditional coordination methods of Danish architects and engineers. This corresponds to a saving of 80,000 to 120,000 euros per 1,000 m2 of construction.

Collisions are costly to correct as they often cause conflicts of responsibility, expensive ad hoc solutions, dissatisfaction and inefficiency on the job site. At Exigo, we ensure that the project material and 3D models are well-coordinated across disciplines before the project is sent out.

Interdisciplinary coordination

We have prepared a solution so that as a customer you can see at every review whether the architect or engineer has changed anything lately. You get images of the 3D models, with a clear color code showing what changes have occurred since the last review. You can also see the individual alterations in an interactive dashboard.

The interdisciplinary coordination is generally not paid enough attention to by architects and engineers – despite clear contractual relationships. Among others, we have experienced this during projects for the Danish Construction Authority and the City of Aarhus. Exigo’s independent collision control was an important tool to ensure well-coordinated projects from start to finish. In addition, collision control has saved developers many additional costs in the two projects.

Independent collision control

At Exigo, we conduct an independent collision control. We have no hidden plans but focus on your needs – your success is our success.

We can perform the collision control as a complete control of the reporting of all collisions we have identified. We can also do a random screening, in which we will fully control all 3D models but only give examples of collisions, the extent of the collisions, and make a qualitative assessment of the project status in terms of coordination.

Find security in the 3D models

Make sure the 3D models are of the required quality and form a solid foundation for a buildable project. That gives the stomach rest. Contact us and we will find out how we can help you.
